项目/Item

· 参数/ Parameter

定位系统/ Position System

双相机/Double Camera

YAMAHA 400机械手臂/ YAMAHA 400-Mechanical Arm

过胶部分/Gluing

机械凸轮飞达送纸/ Mechanical Cam Feeding

贴角部分/Corner Pasting

飞达吸板式送板/Bord Feeding

面纸尺寸（L*W）/Size of Paper

L  180-880mm

W  95-600mm

成品（纸盒）尺寸（L*W*H）/Size of Box

L  70-400mm

W  60-400mm

H  15-120mm

最大折入深度/ Max Folding Depth

80mm

面纸厚度/Paper  Thickness

80-180g/㎡

生产速度/ Production Speed

16-25pcs/min

定位精度/ Positioning Accuracy

±0.1mm

面纸最大放置高度/Paper Max Placing Height

800mm

纸板厚度/Board Thickness

1-3mm

空压机/Air Compressor

0.6-0.8MPa

胶桶容量/ Glue Bucket Capacity

30KG

电源/Power

380V/50Hz/3phases

额定功率/ Power Rating

22KW

机器重量/Weight

5000KG

整机尺寸/ Size of Machine

带贴角机/With Pasting Machine

L6400×W3900×H2850mm

无贴角机 /Without Pasting Machine

 L6400×W3000×H2850mm
